AJA OG-FIDO-T-MM 1-Channel 3G-SDI Multi-Mode Transmitter

£1,092.00 £910.00

Order Now - Usually delivered in 2-4 weeks

SKU: AJA-OG-FIDO-T-MM Categories: , Tag:

OG-FiDO-T-MM offers unmatched flexibility and cost efficiency for 3G-SDI Fiber conversion, allowing for cable runs up to 700 m (2296 ft) for OM4 and 300 m (984 ft) for OM3 for Multi-Mode* fiber optic cables – useful for eliminating ground loop problems.

Designed for use in high density openGear 2RU frames including AJA’s OG-X-FR frame, new DashBoard software support on Windows, macOS and Linux offers remote control and monitoring of the openGear architecture and provides convenient and industry standard configuration, monitoring and control options over a PC or local network.

Connectivity

The 3G-SDI input is reclocked with best in class input jitter tolerance. A reclocked looping 3G-SDI output is also provided. 3G-SDI rates of 270Mb, 1.5Gb, and 3Gb are supported. Supports Multi-Mode fibre cable.

Open Gear Compatibility

The openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.

Ethernet Access

A standard Ethernet connection allows the frame to be accessed via the Dashboard application for overall frame communication. Optional per-card Ethernet access can be installed in the frame for advanced communication with compatible openGear cards.The optional redundant power supply provides a secondary power source in the event of a primary power failure.

Flexible I/O

The modular rear panel allows custom I/O connections per card (included with individual cards).

Failsafe

The optional redundant power supply provides a secondary power source in the event of a primary power failure.

Additional information

BRAND

AJA

MPN

OG-FIDO-T-MM

Specification

Video Formats

  • 150 Mbps – 3 Gbps, format agnostic

Video Input Digital

  • 1-Channel independent 3G-SDI Input with SDI Loop out, SMPTE-259/292/424

Video Output Digital

  • 1-Channel independent 3G-SDI BNC Output, SMPTE-259/292/424
  • 1-Channel Multi-Mode LC Fiber connector, SMPTE-297
  • Nominal Wavelength: 850 nm
  • Optical Power: -7dBm (min), -2dBm (max)
  • Extinction Ratio: 7.5dB (Typ)

Reclocking

  • 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps – Auto Select
  • All other rates are passed through and not reclocked

User Interface

  • openGear DashBoard network control software via Windows, macOS or Linux

Size (w x d x h)

  • openGear standard form factor, front slot and rear card. Two slots required for each card.

Weight

  • 0.5 lb (0.3 kg)

Power

  • openGear frame compatible, 2.5 watts max per card

Environment

  • Safe Operating Temperature: 0 to 40 C (32 to 104 F)
  • Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)



Features

  • Video Formats: 150 Mbps – 3 Gbps, format agnostic
  • Inputs: 1x 3G-SDI with SDI Loop out
  • Outputs: 1x 3G-SDI BNC Output; 1x Multi-Mode LC Fiber Output
  • Monitor via openGear DashBoard
  • Input Present and Input SMPTE Lock LEDs
  • Automatic detection and reclocking
  • 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps – Auto Select
  • Nominal Wavelength: 850 nm
  • Power: 2.5 watts
  • Hot swap capable
  • Compatible with OG-X-FR, OG-3-FR and DFR-8321 openGear frames
