Bolin D2-220H Dante AV-H FHD PTZ Camera – Black

Bolin D2-220H Dante AV-H FHD PTZ Camera – Black (D2-220H) features a 1/2.8″ CMOS sensor to capture resolutions up to 1080p60. The built-in zoom lens has an optical zoom range of 20x, and you can zoom in further with the 16x digital zoom. The camera compresses using HEVC/H.265 (via IP) or H.264 (via IP/Dante AV), and you can transmit up to two streams at the same time using RTSP or RTMP protocols up to 1080p60.

With 255 programmable preset positions and 6 presets on the included IR remote, you can set the camera to rapidly move between positions using the IP, RS-232, RS-422/RS-485, or IR control with separately available controllers. The camera supports external audio input via a 3.5mm stereo mic/line-level jack, and it transports up to eight channels of Dante audio.

The camera can be powered using PoE+ or with the included AC adapter. It can sit on a flat surface or be mounted using a separately available ceiling or wall mount bracket.

What is Dante AV-H™ (Quoted From Audinate)

• Dante AV-H™  is software for SoC-based video products that bring mature, comprehensive user control and management to H.264 AV-over-IP, delivering compatibility with any Dante audio network devices. Now, interoperability
  with AV-over-IP products from multiple vendors is a reality, letting users connect, manage and configure all networked video and audio connections in a single Dante Controller window.
• Dante AV H brings 8 channels of Dante audio to your video products for instant compatibility with existing and planned installations, easing technical requirements and simplifying system design.

Powered By Dante AV-H™

Just like Bolin’s Dante AV Ultra™ line of products, designed to seamlessly integrate into an existing Dante audio ecosystem, Bolin’s D2-210H/D2-220H PTZ camera is managed using optimized light-weight H.264 codec with the Dante AV-H™ software to provide low cost and lower bandwidth AV Over IP stream with the flexibility to independently route multiple audio and video in 1G network. More information about Dante AV.

High-Quality Imaging – Full HD

Bolin’s Dante AV-H™ PTZ cameras are equipped with Sony sensor to provide brilliant, high-quality images in 1080p60 resolutions with 10x and 20x optical zoom.

Video Output

Deliver Dante AV-H™ version IP streaming video to the Dante network, and local HDMI video and USB streaming output to conventional workflows in FHD. D2-220H also provides 3G-SDI, lossless baseband video for live production use.

Multicast Mode

Point to Multipoint and Point-to-Point Distribution – supports both unicast and multicast video distribution.

Video Settings

Image parameter adjustments include exposure, focus, iris, shutter speed, white balance, gamma, wide dynamic range, image stabilizer, flip/mirror, and more with configurable video settings.

Audio

HDMI/SDI/USB embedded high–quality audio and Dante AV™ video streaming embedded audio with support for Mic-in and Line-in audio input. The audio that is input to the camera can be routed within a Dante audio over IP system.

PTZ Movement

Extremely quiet and smooth operation for Pan/Tilt movements combined with enhanced adaptive, variable, and super slow speed control provides accurate and effective operation experiences. Picture Profile Preset- Image parameter setting restore with presets and quick access operation.

Ease of Installation and Use

Simply connect one network cable from camera to any 1GB Ethernet network/POE device to access to existing Dante Audio-Over-IP system.

Always Up to Date

Firmware updates, upgrade via USB and IP interface to keep Dante AV-H camera features and performance up to date.

Comes With

• x1 Bolin D2-220H Dante AV-H FHD PTZ Camera – Black
• x1 IR Remote Control
• x1 Power Adapter
• x1 Power Cable
• x1 HDMI Cable Mount
• x1 RJ45 to RS-232 8-Pin Control Cable Adapter
• x1 RJ45 to RS-422 Serial Control Cable Adapter
• x1 Set of Screws
