Bolin VCC-M2H10BI-4FN1/B FHD PTZ Camera
£690.00 £575.00
Bolin VCC-M2H10BI-4FN1/B FHD PTZ Camera is a compact design one camera solution for many purposes. It fits in most video production workflows – functional video conference camera with capabilities to enter the world of broadcast.
Simultaneous video output of 3G-SDI, HDMI, IP, USB2.0, or independently.
Cloud video conference, easy RTMP and RTSP streaming, quiet and smooth movements with camera pre-sets, web interface to configure, view, and move the camera on the fly – the power is in your hands.
Video Output
Simultaneous 3G-SDI, HDMI1.4, FHD IP, USB2.0
Quiet and smooth speed adjustable PTZ movements, 6 speed of preset adjustable.
Lens
Zoom: Optical 10X; Digital 2X. Provides 61° Horizontal wide angle of View for huddle space conference or small studio use.
Audio Embedded with Video Output
With mic built-in and audio Line-in available, audio embedded with SDI and HDMI output plus bi-directional audio IP streaming over network.
Full HD Image Quality with 60fps Frame Rate
SDI/HDMI video resolution supports up to 1080p60, 1080i59.94; IP video resolution up to 1080P60. FHD high frame rate (60fps) operation ensures capturing fast, spontaneous action and smoother, more fluid reproduction of moving subjects.
Keep Up-To-Date
USB & IP Firmware upgrade interface provides capability of constantly improving the camera features and performances, even for customized function upgrades.
Industry Standard and Compatibility
SDI: SMPTE compliant SDI broadcast and ProAV workflow standards. HDMI: Provision of an HDMI video interface simplifies direct connection with a compatible video conferencing system, PC or HD video monitor.
Installation Made Easy
Move it around using it for USB cloud conferencing camera. Installation is simplified in a wide range of environments. Convenience of wiring, RJ45 RS232/422 control port. PoE power option to reduce power cabling requirements. Standard/ceiling/tripod mount with E-Flip function.
You Have It Under Control
Supports traditional serial RS232, RS422/485 via VISCA and Pelco P/D protocol, and IP remote control over network via Visca-over-IP and Onvif IP protocol, IR remote control.
Power
12VDC, PoE+ (IEEE 802.3at)
Image Profile Pre-sets
Image parameter setting restore with pre-sets and quick access operation.
Body Colour Availability
Black
Comes With
- 1X Bolin VCC-M2H10BI-4FN1/B FHD PTZ Camera
- IR Remote Controller R2
- USB Port To 3.5mm Audio Jack Adapter
Additional information
| BRAND | Bolin |
|---|
Specification
| Image Sensor | 1/2.8 inch CMOS 2.13MP | |
|---|---|---|
| Lens 10X | 4.7~47mm. 16X digital zoom | |
| Digital Zoom | 16X | |
| Horizontal Angle of View | 60.9°(W)~6.43°(T) | |
| Aperture | F1.6(W)~F3.0(T) | |
| Min. Illumination | 0.5Lux (Day), 0.1Lux (Night) | |
| Focus | Auto Focus, Manual Focus, | |
| White Balance | AUTO, ATW, Indoor, Outdoor, One Push WB, Manual WB | |
| Exposure | Full Auto, Shutter Priority, Iris Priority, Manual, Bright, | |
| Features | Defog mode, Flipper, Mirror, De-Flicker, WDR | |
| Noise Reduction | 2D/3D | |
| S/N Ratio | ≥50db | |
