Ikegami HQLM-3125X 31-Inch 4K Multi-Format LCD Monitor

Description

[vc_row][vc_column][vc_column_text]The HQLM-3125X is a Grade-1 4K HDR Master monitor and represents a new dimension in critical image evaluation. It employs a ground-breaking Double-Layer LCD 4,096×2,160 pixel 10-bit resolution panel with 1.000 Nits and a contrast ratio of 1,000,000:1. 2x 12G-SDI, 3x 3G-SDI In- & Outputs and 1x HDMI are available as standard features. When it comes to 3G-SDI×4, square-division and two-sample interleave are available. A wide critical viewing angle of 178° (horizontal/vertical) allows users to see accurately displayed images from any angle.

Convenient features such as Multi-Viewer-Screen, Side-By-Side Video, Audio Meters, User Markers and R/G/Y Tally make the Ikegami HQLM monitor series the ideal companion for broadcast productions. The HQLM-3125X additionally features an integrated Gamut Marker (BT.709 outbound colours are highlighted), 1D/3D LUT support and Payload ID recognition for automatic monitor setting adjustment.

Supporting various EOTF tables (HLG, PQ, S-Log, DCI-P3, …) and Wide Colour Gamut BT.2020 as well as conventional BT.709, the HQLM-3120W is the ideal solution for 4K grading suites.

• Diverse Input Signal Formats
• 1.000 Nits / 1Million:1 Contrast
• UHD LCD Panel
• Gamut Marker
• 1D/3D LUT Support
• Faithful Color Reproduction
• 12G-SDI and 3G-SDI In-/Outputs

• Compatibility with embedded audio
• Built-in Marker Function
• User Marker Display Function
• Shadow Function
• Remote Control via Ethernet or RS-485
• Various built-in Test Signals
• Waveform Monitor/Vectorscope Display Functions
• Timecode Display Function
• HDR mode and colour space setting by Payload ID
• Dot-by-Dot Display Function
• Multi-Viewer-Screen and  Side-By-Side Picture Mode
• 5.1ch Surround Down-Mix Output
• Image & Test Signal MIX Functions
• IMD/UMD: TSL V3.1 & V5.0 Support
