Panasonic Lumix S5D with 18-40mm Lens
£1,398.00 £1,165.00
Panasonic Lumix S5D with 18-40mm Lens (DC-S5DNE-K) delivers superb video performance and is capable of 4K 60p/50p 4:2:0 10-bit, and 4K 30p/25p 4:2:2 10-bit internal recording up to 30 minutes. It is also capable of 4K 60p/50p 4:2:2 10-bit HDMI output. For 4K 30p/25p 4:2:0 8-bit internal recording, there is no time limit.
In addition to C4K video recording, the LUMIX S5D is capable of RAW video data output to ATOMOS NINJA V over HDMI at a resolution of 5.9K (5888×3312) 29.97p/25p, 4.1K (4128×2176) 59.94p/50p and Anamorphic 3.5K (3536×2656)/50p. A variety of video recording assist functions such as the Vector Scope Display, Master Pedestal Adjustment and SS/Gain Operation(SEC/ISO, ANGLE/ISO, SEC/dB) are also available.
The LUMIX S5D delivers 14+ stops of dynamic range, virtually the same as those of the Panasonic cinema cameras, to precisely reproduce everything from dark to bright areas. The ability to capture accurate colours and skin tones is a must for any filmmaker. The LUMIX S5D imports the renowned colour science of Panasonic’s VariCam line-up of cinema cameras, as well as V-Log / V-Gamut.
With Slow & Quick mode, impressive video slow and quick motion in 4K (1-60fps, 30x quick to 2.5x slow) or in FHD (1-180fps, 60x quick to 7.5x slow) is available.
DJI LiDAR AF ready
When the S5D is paired with DJI LiDAR Range Finder Module and DJI RS 3 Pro Gimbal, distance measurement information is sent to the camera via USB, and the camera drives the focus, so no focus motor is required, enabling easier handling with a more compact size and greater freedom of shooting. Furthermore, there is no need for lens calibration adjustments, which saves setup time. Thanks to the LiDAR’s high-speed 43,200 ranging points within a 14-meter distance, extremely fast AF is realized, which is also effective when shooting in low-light conditions.
High image quality even in low light situations with Dual I.S. to suppress blurring
The LUMIX S5D boasts a wide dynamic range and reproduces sharp images with exceptional clarity. Noise is minimised even when shooting at maximum ISO 51200 high sensitivity, making it an ideal camera to use in low-light situations.
The LUMIX S5D features Dual Native ISO sensitivity, a technology that was first introduced in the Panasonic professional cinema camera VariCam line-up. Normally, noise increases as sensitivity rises with a single native ISO image sensor. However, the image sensor with Dual Native ISO in the S5D minimises noise generation by choosing an optimal circuit to use according to the sensitivity before gain processing. As a result, it allows a maximum of ISO 51200 high sensitivity recording. Dual Native ISO gives film creators a greater variety of artistic choices as well as the ability to use less light on set, saving time. The LUMIX S5D’s Dual Native ISOs are 640 and 4000.*1
The LUMIX S5D integrates the Body I.S. (Image Stabiliser) for powerful handshake correction. Panasonic developed an algorithm that precisely calculates shake information acquired not only from the gyrosensor, but also from the image sensor and accelerometer sensor. This enables more accurate shake detection and compensation, making it possible to use a 5-stop slower shutter speed*2. Combining the Body I.S. (5-axis) in the camera and the O.I.S. (Optical Image Stabiliser, 2-axis) in the LUMIX S Series lens the 5-axis Dual I.S.2 compensates for blurring, allowing the use of a 6.5-stop slower shutter speed*3.
It is highly beneficial in telephoto shots and in adverse situations, such as in low-light or one-handed shooting. The 5-axis Dual I.S.2 works for both photo and video recording, including 4K. The Body I.S. compensates for camera movement even when other L-Mount lenses without O.I.S. are used.
*1 When recording mode is set to V-Log. The sensitivity varies depending on the recording mode.
*2 Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=60mm when S-R2060 is used.
*3 Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=200mm when S-E70200 is used. Firmware must be updated to the latest version.
Reliable and flexible for optimum creative freedom
The compact LUMIX S5D boasts outstanding mobility while still achieving exceptional performance. To withstand heavy field use, the LUMIX S5D is composed of a magnesium alloy full die-cast body and is splash/dust-resistant*1. With an optimum layout of heat dispersion components, heat is effectively transferred outside which results in stable, continuous video recording for long periods.
The LUMIX S5D has a large LVF (Live View Finder) with a high magnification ratio of approx. 0.74x, as well as a high-precision, high-speed OLED (Organic Light-Emitting Diode) display which features a 2,360K-dot high resolution. Adoption of OLED for the LVF achieves high speed response with minimum time lag of less than 0.005 sec. With an eyepoint of approximately 20 mm, it offers high visibility with comfort for users wearing glasses.
A 3.0-inch free-angle LCD in 3:2 aspect with 1,840K-dot high resolution provides touch control. Composition during recording in various popular aspect ratios such as 16:9, 4:3, 1:1, 4:5, 5:4 and 9:16 can be checked with the Frame Marker function. A REC Frame Indicator identifies whether the camera is recording or not.
The LUMIX S5D has a double SD Memory Card slot – one slot complies with UHS-I and the other with the high-speed, high-capacity UHS-II (Video Class 90).
The camera’s battery can be recharged either via AC or USB according to the user’s convenience.
*1 Dust and Splash Resistant does not guarantee that damage will not occur if this lens is subjected to direct contact with dust and water.
Comes With
- 1x Lumix S5D Body
- 1x LUMIX S 18-40mm F4.5-6.3 Lens
- 1x Body Cap
- 1x Hot Shoe Cover
- 1x Cover for the Battery Grip Connector
- 1x Shoulder Strap
- 1x Battery Pack
- 1x Lens Cap
- 1x Lens Rear Cap
Additional information
| BRAND | PANASONIC |
|---|
Specification
| Type | Digital Single Lens Mirrorless camera |
| Lens mount | L-Mount |
| IMAGE SENSOR | |
| Type | 35mm full-frame (35.6mm x 23.8mm) CMOS sensor |
| Camera effective pixels / Total pixels | 24.20 megapixels / 25.28 megapixels |
| AR (Anti Reflection) coating | Yes |
| Aspect ratio / Color filter | 3:2 / Primary color filter |
| Dust reduction system | Image sensor shift type |
| LATITUDE | 14+ stops (V-Log) |
| STILL IMAGE | |
| Recording file format | |
| Still image | JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072) |
| 6K PHOTO** / 4K PHOTO** | 6K PHOTO: MP4 (H.265/HEVC, Audio format: AAC (2ch)) 4K PHOTO: MP4 (H.264/MPEG-4 AVC, Audio format: AAC (2ch)) Extracted still images: JPEG (DCF, Exif 2.31) |
| Aspect ratio | 4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1 |
| File size (Pixels) | |
| When using full-frame lenses | |
| 3:2 | 6000×4000(L) / 4272×2848(M) / 3024×2016(S) / 12000×8000(XL)* / 8496×5664(LL)* *High Resolution Mode. 5184×3456(6K PHOTO) / 3504×2336(4K PHOTO) / 5984×4000(HLG PHOTO, Full-Res.) / 3232×2160(HLG PHOTO, 4K-Res.) |
| 4:3 | 5328×4000(L) / 3792×2848(M) / 2688×2016(S) / 10656×8000(XL)* / 7552×5664(LL)* *High Resolution Mode. 4992×3744(6K PHOTO) / 3328×2496(4K PHOTO) / 5312×3984(HLG PHOTO, Full-Res.) / 2880×2160(HLG PHOTO, 4K-Res.) |
| 16:9 | 6000×3368(L) / 4272×2400(M) / 3024×1704(S) / 12000×6736(XL)* / 8496×4784(LL)* *High Resolution Mode. 3840×2160(4K PHOTO) / 5888×3312(HLG PHOTO, Full-Res.) / 3840×2160(HLG PHOTO, 4K-Res.) |
| 1:1 | 4000×4000(L) / 2848×2848(M) / 2016×2016(S) / 8000×8000(XL)* / 5664×5664(LL)* *High Resolution Mode. 2880×2880(4K PHOTO) / 4000×4000(HLG PHOTO, Full-Res.) / 2144×2144(HLG PHOTO, 4K-Res.) |
| 65:24 | 6000×2208(L) |
| 2:1 | 6000×3000(L) |
| When using APS-C/Super 35mm lenses | |
| 3:2 | 3984×2656(L) / 2880×1920(M) / 2064×1376(S) / 3504×2336(4K PHOTO) |
| 4:3 | 3536×2656(L) / 2560×1920(M) / 1840×1376(S) / 3328×2496(4K PHOTO) |
| 16:9 | 3984×2240(L) / 2880×1624(M) / 1920×1080(S) / 3840×2160(4K PHOTO) |
| 1:1 | 2656×2656(L) / 1920×1920(M) / 1376×1376(S) / 2880×2880(4K PHOTO) |
| Image quality | RAW / RAW+Fine / RAW+Standard / Fine / Standard |
| Color space | sRGB, AdobeRGB |
| MOTION PICTURE | |
| Recording file format | MOV: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: LPCM (2ch 48kHz/16-bit)) MP4: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: AAC (2ch)) |
| Switch NTSC / PAL | Yes (NTSC (59.94Hz) / PAL(50.00Hz)) |
| HDMI RAW DATA OUTPUT | |
| Compatible external devices | ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.55 or higher) Blackmagic Video Assist 5″ 12G HDR, Blackmagic Video Assist 7″ 12G HDR (version 3.43 or higher) *This does not guarantee all of the capabilities that the compatible external recorder may have. |
| Rec quality | |
| NTSC (59.94Hz) | |
| Full-frame | [5.9K] 5888×3312 29.97p, 12-bit (LPCM) 23.98p, 12-bit (LPCM) |
| APS-C | [4K] 4128×2176 (17:9) 59.94p, 12-bit (LPCM) 29.97p, 12-bit (LPCM) 23.98p, 12-bit (LPCM) |
| [Anamorphic 3.5K] 3536×2656 (4:3) | 29.97p, 12-bit (LPCM) 23.98p, 12-bit (LPCM) |
| PAL (50.00Hz) | |
| Full-frame | [5.9K] 5888×3312 25.00p, 12-bit (LPCM) |
| APS-C | [4K] 4128×2176 (17:9) 50.00p, 12-bit (LPCM) 25.00p, 12-bit (LPCM) |
| [Anamorphic 3.5K] | 3536×2656 (4:3) 50.00p, 12-bit (LPCM) 25.00p, 12-bit (LPCM) |
| Audio format | LPCM (2ch 48kHz/16-bit) |
| SLOW & QUICK | |
| MP4** | |
| NTSC (59.94Hz) | Full-frame [FHD] 1920×1080 59.94p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 29.97p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 23.98p, 24Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 1, 2, 5, 10, 15, 30, 60, 100, 120, 150*, 180* fps *Angle of view narrows if you select a frame rate with a number of frames 180. The AF mode switches to MF when the frame rate is set to of 150 fps or more. |
| APS-C / Pixel by Pixel | [4K] 3840×2160 29.97p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 23.98p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 1, 2, 5, 10, 15, 30, 60 fps |
| PAL (50.00Hz) | Full-frame [FHD] 1920×1080 50.00p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 25.00p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 1, 2, 5, 10, 15, 30, 60, 100, 120, 150*, 180* fps *Angle of view narrows if you select a frame rate with a number of frames 180. The AF mode switches to MF when the frame rate is set to of 150 fps or more. |
| APS-C / Pixel by Pixel | [4K] 3840×2160 25.00p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) 1, 2, 5, 10, 15, 30, 60 fps |
| VIEWFINDER | |
| Type | OLED Live View Finder |
| Pixels | Approx. 2.36 million dots |
| Field of view / Magnification | Approx. 100% / Approx. 0.74x with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 3:2 |
| Eye point / Diopter adjustment | Approx. 20 mm at infinity; -1.0 m-1 / -4.0 – +4.0 (dpt) |
| Eye sensor | Yes |
| Display speed | 120fps / 60fps |
| Display time lag | Approx. 0.005sec |
| REAR MONITOR | |
| Type | TFT LCD monitor with static touch control |
| Monitor size | Free-angle, 3.0-inch (about 7.62cm), 3:2 aspect |
| Pixels | Approx. 1.84 million dots |
| Field of view | Approx. 100% |
| FOCUS | |
| Type | Contrast AF system |
| DFD technology | Yes |
| Focus mode | AFS (Single) / AFC (Continuous) / MF |
| AF mode | Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+* / 1-Area* / Pinpoint / Custom 1, 2, 3 (Full area touch is available) (Scalable AF frame size and flexible AF position) *Human/Animal Detection AF can be set ON or OFF. |
| AF detective range | EV -6 – 20 (F1.4, ISO100 equivalent, AFS) |
| AF custom setting | AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction |
| AF assist lamp | Yes |
| AF | lock Set the Fn button in custom menu to AF lock |
| Post Focus / Focus Stacking | Yes / Yes |
| Others | AF-ON, AF-ON: Near Shift, AF-ON: Far Shift, Shutter AF, Half Press Release, Focus/Shutter Priority, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF-Point Scope Setting, AF+MF, MF Guide, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter, Focus Switching for Vert/Hor, Focus Ring Lock, Show/Hide AF Mode, 1-Area AF Moving Speed, Loop Movement Focus Frame, AFC Start Point (225-Area), Lens Focus Resume, Focus Ring Control |
| EXPOSURE CONTROL | |
| Light metering system | 1,728-zone multi-pattern sensing system |
| Light metering mode | Multiple / Center Weighted / Spot / Highlight Weighted |
| Metering range | EV0-18 (F2.0 lens, ISO100 equivalent) |
| Mode dial | Program AE (P) / Aperture Priority AE (A) / Shutter Priority AE (S) / Manual Exposure (M) / Creative Video (P/A/S/M)* / Slow&Quick / Custom 1, 2, 3 / Intelligent Auto *The same exposure operations as P/A/S/M mode is available. |
| ISO sensitivity (Standard output sensitivity) | Auto / 50* / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO |
| Dual Native ISO | [Normal] Native ISO: 100, 640 Auto: Auto / 50* / 100-51200 / 102400* / 204800* *Extended ISO [V-Log] Native ISO: 640, 4000 Auto: Auto / 320* / 640-51200 *Extended ISO [HLG] Native ISO: 400, 2500 Auto: Auto / 400-51200 / 102400* / 204800* *Extended ISO [Cinelike D2 / Cinelike V2] Native ISO: 200, 1250 Auto: Auto / 100* / 200-51200 / 102400* / 204800* *Extended ISO |
| Exposure compensation | 1/3 EV step ±5EV (±3EV for motion picture) |
| AE lock | Set the Fn button in custom menu to AE lock |
| IMAGE STABILIZATION SYSTEM | Image sensor shift type (5-axis / 5.0-stop*) *Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=60mm when S-R2060 is used.] Dual I.S. (6.5-stop* Dual I.S. 2 compatible) *Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=200mm when S-E70200 is used.] |
| WHITE BALANCE | |
| White balance | AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4 |
| White balance adjustment | Blue/Amber bias, Magenta/Green bias |
| Color temperature setting | 2500-10000K in 100K |
| SHUTTER | |
| Type | Focal-plane shutter |
| Shutter speed | Still image: Bulb (Max. 30 minutes), 1/8,000 – 60 Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 – 60 Electronic shutter: Bulb (Max. 60 sec), 1/8,000 – 60 Motion picture: 1/16,000 – 1/25 Creative Video M mode / MF mode: 1/16,000 – 1/2 |
| Self timer | 10sec, 3 images / 2sec / 10sec |
| Remote control | Remote control by DMW-RS2 (sold separately) |
| Silent mode / Shutter type | Yes / Yes (Auto / Mechanical / Electronic front curtain / Electronic / Electronic+NR) |
| BRACKET | |
| AE bracket | 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst |
| Aperture bracket | 3, 5 or all positions in 1 EV step |
| Focus bracket | 1 to 999 images, focus steps can be set in 10 levels |
| White balance bracket | 3 images in blue/amber axis or in magenta/green axis, color temperature setting |
| BURST SHOOTING | |
| Burst speed | |
| Mechanical shutter / Electronic front curtain shutter | AFS/MF: H: 7 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) AFC: H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Electronic shutter | AFS/MF: H: 7 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) AFC: H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Number of recordable images | RAW / RAW+JPEG: More than 24 images JPEG: More than 999 images (When using a card with SD Speed Class with “UHS-II UHS Speed Class 3 (U3)” inserted into card slot 1.) * When recording is performed under the test conditions specified by Panasonic. |
| 6K PHOTO** / 4K PHOTO** | |
| Burst speed | 6K PHOTO: 30 frames/sec 4K PHOTO: 60 frames/sec, 30 frames/sec |
| Exif information | Yes (Each JPEG image cropped out of the 6K/4K burst file complies with EXIF.) |
| FLASH | |
| Flash type | TTL External Flash (sold separately) |
| Flash mode | Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced |
| Off *For iA only. | |
| Flash synchronization | 1st Curtain Sync, 2nd Curtain Sync. |
| Flash output adjustment | 1/3EV step ±3EV |
| Synchronization speed | Less than 1/250 second *The guide number decreases at 1/250 second. Only when set to M mode or S mode. |
| Wireless control | Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1ch/2ch/3ch/4ch |
| EXTRA TELE CONVERSION | 2.0x (EX S) (When using full-frame lenses), 1.9x (EX S) (When using APS-C / Super 35mm lenses), 1.4x (EX M) *Only for still image recording. |
| PHOTO STYLE | |
| Photo Style | Standard / Vivid / Natural / L. Classic Neo / Flat / Landscape / Portrait / Monochrome / L. Monochrome / L. Monochrome D / L. Monochrome S / Cinelike D2 / Cinelike V2 / Like709 / V-Log / Standard (HLG) / Monochrome (HLG) / Like2100 (HLG) / My Photo Style 1-10 |
| Picture adjustment | Contrast / Highlight / Shadow / Saturation / Color Tone / Hue / Filter Effect / Grain Effect / Color Noise / Sharpness / Noise Reduction / ISO / WB *Adjustable settings vary depending on the Photo Style mode. |
| FILTER | Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine* *For photos only. |
| MOTION PICTURE FUNCTION | |
| Vertical Position Information | ON / OFF |
| Master pedestal level | 31 steps |
| Luminance level | 8-bit: 0-255 / 16-235 / 16-255 |
| 10-bit: 0‒1023 / 64‒940 / 64‒1023 | |
| Wave form monitor / Vectorscope | Selectable |
| LUT display | LUT View Assist (Monitor) / LUT View Assist (HDMI) |
| Time code | Count Up: Rec Run/Free Run selectable, Time Code Mode: Drop frame/Non-drop frame selectable (When NTSC (59.94Hz) is selected.) |
| SS/Gain operation | Shutter Duration/ISO / Angle/ISO / Shutter Duration/dB |
| Knee control | Yes (in Like709 mode) |
| FUNCTION BUTTON | |
| REC | Exposure Comp. / Sensitivity / White Balance / Photo Style / Metering Mode / Aspect Ratio / Picture Quality / Picture Size / HLG Photo / High Resolution Mode / 1 Shot Spot Metering / Long Exposure NR / Min. Shutter Speed / 1 Shot RAW+JPG / i.Dynamic Range / Filter Effect / One Push AE / Touch AE / Exposure Mode / AF Mode / AF Custom Setting(Photo) / AF Custom Setting(Video) / Focus Peaking / Focus Peaking Sensitivity / 1-Area AF Moving Speed / Focus Ring Lock / AE LOCK / AF LOCK / AF/AE LOCK / AF-ON / AF-ON: Near Shift / AF-ON: Far Shift / AF-Point Scope / Focus Area Set / Flash Mode / Flash Adjust. / Wireless Flash Setup / Drive Mode / 1 Shot “6K/4K PHOTO” / Bracketing / Silent Mode / Image Stabilizer / Shutter Type / Ex. Tele Conv. / Live View Composite / Post-Focus / Motion Pic. Rec File Format / Motion Pic. Rec Quality / Slow & Quick Setting / Time Code Display / Sound Rec Level Disp. / Sound Rec Level Adj. / Sound Rec Level Limiter / Special Mic. Directivity Adjust / Image Stabilizer / E-Stabilization (Video) / Boost I.S. (Video) / Image Area of Video / Live Cropping / Q.MENU / Rec / Playback Switch / Video Record / LVF/Monitor Switch / Operation Lock / Dial Operation Switch / Preview / Preview Aperture Effect / Constant Preview / Level Gauge / Histogram / Luminance Spot Meter / Frame Marker / Photo Grid Line / Live View Boost / Monochrome Live View / Night Mode / LVF/Monitor Disp. Style / Photo/Video Preview / Zebra Pattern / LUT View Assist (Monitor) / LUT View Assist (HDMI) / LUT Select / HLG View Assist(Monitor) / HLG View Assist (HDMI) / Sheer Overlay / I.S. Status Scope / WFM/Vector Scope / Anamorphic Desqueeze Display / Focus Ring Control/ Zoom Control / Destination Card Slot / Wi-Fi / No Setting / Restore to Default |
| PLAY | Magnify from AF Point / LUT View Assist (Monitor) / HLG View Assist (Monitor) / Anamorphic Desqueeze Display / RAW Processing / 6K/4K PHOTO Bulk Saving / Delete Single / Protect / Rating 1, 2, 3, 4, 5 / Copy / Rec/Playback Switch / LVF/Monitor Switch / Video Record / Night Mode / Card Slot Change / Wi-Fi / Send Image (Smartphone) / LUT View Assist (HDMI) / HLG View Assist (HDMI) / 6K/4K Photo Play / No Setting / Off (Disable Press and Hold) / Restore to Default |
| LEVEL GAUGE | Yes |
| ictBridge compatible | |
| INTERFACE | |
| USB | SB Type-C® (USB 10Gbps) |
| HDMI*** | |
| Monitor-through | When a mode other than [C4K/60p]/[C4K/50p]/[4K/60p]/[4K/50p] is selected for [Rec Quality]: 4:2:2 10bit, 4:2:2 8bit, 4:2:0 8bit When [C4K/60p]/[C4K/50p/[4K/60p]/[4K/50p] mode is selected in [Rec Quality]: 4:2:2 10bit*, 4:2:0 8bit *When 4:2:2 10bit mode is selected, it is not possible to record motion picture or still picture on the memory card in the camera unit. Info Display: ON / OFF (selectable) HLG View Assist (HDMI): AUTO / MODE1 / MODE2 / OFF (selectable) |
| Playback | microHDMI TypeD / VIERA Link, Audio: Stereo NTSC (59.94Hz): Auto / C4K/60p / 4K/60p / 4K/30p / 1080p / 1080i / 720p / 480p PAL (50.00Hz): Auto / C4K/50p / 4K/50p / 4K/25p / 1080p / 1080i / 720p / 576p |
| Remote input | φ2.5mm |
| External microphone / external audio device input | φ3.5mm for external microphone / external audio device MIC (Plug-in Power) / MIC / LINE is selectable. Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (sold separately). |
| Headphone output | φ3.5mm |
| Microphone | Stereo, Wind Noise Canceller: OFF / Low* / Standard / High *When attaching DMW-MS2 (sold separately). |
| XLR microphone | Yes with DMW-XLR1 (sold separately) |
| Speaker | Monaural |
| SD card slot | SD Memory Card, SDHC Memory Card, SDXC Memory Card Slot 1: Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards. Slot 2: Compatible with UHS-I UHS Speed Class 3 standard SDHC/SDXC Memory Cards. |
| WIRELESS | |
| Wi-Fi | 2.4GHz bands (STA/AP) (IEEE802.11b/g/n) 5GHz bands (STA) (IEEE 802.11a/n/ac) Please refer to “Wi-Fi” Sheet |
| Bluetooth | Bluetooth® v4.2 (Bluetooth Low Energy (BLE)) |
| DUST AND SPLASH RESISTANT* | Yes. *Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water. |
| POWER | |
| Battery | Li-ion Battery Pack (7.2V, 2200mAh, 16Wh) (bundled) USB power supply, USB power charging |
| Battery life (CIPA standard) | Approx. 430 images (rear monitor), 450 images (LVF), 1,500 images (Power Save LVF mode*) with S-R1840 Approx. 410 images (rear monitor), 430 images (LVF), 1,450 images (Power Save LVF mode*) with S-R28200 *Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec. |
| Continuous recordable time (Motion picture)** | MP4 [FHD/60p]: Approx. 140 min (rear monitor), 140 min (LVF) *When using S-R1840. When the battery is fully charged. MP4 [FHD/60p]: Approx. 130 min (rear monitor), 140 min (LVF) *When using S-R28200. When the battery is fully charged. |
| Actual recordable time (Motion picture)** | MP4 [FHD/60p]: Approx. 70 min (APS-C, Pixel by Pixel) (rear monitor), 70 min (APS-C, Pixel by Pixel) (LVF) *When using S-R1840. When the battery is fully charged. MP4 [FHD/60p]: Approx. 65 min (APS-C, Pixel by Pixel) (rear monitor), 70 min (APS-C, Pixel by Pixel) (LVF) *When using S-R28200. When the battery is fully charged. |
| Battery grip | DMW-BGS5 (sold separately) |
| DIMENSIONS / WEIGHT | |
| Dimensions (W x H x D) | Approx. 132.6 x 97.1 x 81.9 mm / 5.22 x 3.82 x 3.22 inch (excluding protrusions) |
| Weight | Approx. 714g / 1.58 lb (Body, Hot Shoe Cover, Battery, SD Memory Card x 1) (excluding body cap) Approx. 630g / 1.39 lb (Body, Hot Shoe Cover) (excluding body cap) |
| OPERATING ENVIRONMENT | |
| Operating temperature | 0oC to 40oC (32oF to 104oF) |
| Operating humidity | 10%RH to 80％RH |
| STANDARD ACCESSORIES | DC-S5D Kit Body Cap, Hot Shoe Cover, Cover for the Battery Grip Connector, Shoulder Strap, Battery Pack, Lens Cap, Lens Rear Cap ** About motion picture recording / 6K PHOTO/4K PHOTO recording – 6K PHOTO is a high speed burst shooting function that cuts a still image out of a 4:3 or 3:2 video footage with approx. 18-megapixel (approx. 6000 x 3000 effective pixel count) that the 6K image manages. – The cards that can be used for recording vary depending on the motion pictures bit rate and format type. Motion pictures with 72Mbps or less: SD memory card with SD Speed Class with Class 10 or Video Speed Class 10 or higher Motion pictures with 200Mbps or less: SD memory card with UHS-I / UHS-II UHS Speed Class 3 (U3) or Video Speed Class 30 or higher – Recording stops when the continuous recording time exceeds 30 minutes in [C4K/60p] [C4K/50p] [4K/60p] [4K/50p] [4K-A/50p] [C4K/4:2:2 10-bit] [4K/4:2:2 10-bit] [4K-A/4:2:2 10-bit] [4K/4:2:0 10-bit] [4K-A/4:2:0 10-bit] [S&Q]. – Recording stops when the continuous recording time exceeds 15 minutes in [6K PHOTO] [4K PHOTO]. – A new file will be created to continue recording if the continuous recording time exceeds the following conditions. Motion pictures with less than 72Mbps: 30 minutes Motion pictures with 72Mbps or more: 3 hours 4 minutes – A new file will be created to continue recording if the file size exceeds the following conditions. [MP4] in [FHD]: 4GB [MP4] in [4K]: 96GB [MOV]: 192GB – When the ambient temperature is high or continuous recording is performed, the camera may stop the recording to protect itself. Wait until the camera cools down. *** For [C4K/60p] [C4K/50p] [4K/60p] [4K/50p] video output, use an HDMI2.0 cable that has the HDMI logo on it, and that is described as”4K compatible”. |
| LUMIX S 18-40mm F4.5-6.3 | |
| Lens Construction | 8 elements in 7 groups (3 aspherical lenses, 2 ED lenses, 1 UHR lens) (excluding 1 protection element) |
| Mount | L-Mount |
| Optical Image Stabilizer | – |
| Focal Length | f=18-40mm |
| Aperture Type | 7 diaphragm blades / Circular aperture diaphragm |
| Maximum Aperture | F4.5 (Wide) – F6.3 (Tele) |
| Minimum Aperture | F22 (Wide) – F32 (Tele) |
| Closest Focusing Distance | 0.15m/0.49ft (at focal length 18-21mm) / 0.35m/1.15ft (at focal length 40mm) |
| Maximum Magnification | 0.28x (at focal length 21mm) |
| Diagonal Angle of View | 100°(Wide) – 57°(Tele) |
| Dust and Splash Resistant | Yes* |
| Recommended Operating Temperature | -10℃ to 40℃ (14℉ to 104℉) |
| Filter Size | φ62mm |
| Max. Diameter | φ67.9mm / 2.67inch |
| Overall Length | Approx. 40.9mm / 1.61inch (from the tip of the lens to the base side of the lens mount) |
| Weight | Approx. 155g / 0.34lb (excluding lens cap and lens rear cap)B22 |
| Standard Accessories | Lens cap, Lens rear cap |
