Sennheiser XSW-D Portable ENG Set

£315.83 ex. VAT £379.00 inc. VAT

FEATURES
• One touch ease-of-use
• 2.4 GHz digital transmission for worldwide operation
• 75 m range (250 ft) in optimal conditions
• Up to 5 hours battery life on a single charge
• Switch between multiple transmitters linked to one
• receiver
• Mix and match different connector types
• Mute from either transmitter or receiver

Description

Sennheiser XSW-D Portable ENG Set

Sennheiser XSW-D Portable ENG Set

One-touch ease-of-use wireless audio set that utilizes a digital transmission to seamlessly link audio sources. Equipped
with both XLR and 3.5 mm (1/8″) transmitters, this elegant solution makes capturing dialogue on a DSLR easier than ever
before while maintaining a reliable connection.

DELIVERY INCLUDES
• XSW-D 3.5 mm (1/8″) transmitter
• XSW-D female XLR transmitter
• XSW-D 3.5 mm (1/8″) receiver
• ME 2-II clip-on lavalier mic
• 3.5 mm (1/8″) coiled cable
• Cold Shoe mount
• Belt clip
• USB-A to USB-C charging cable
• Colored stickers for labelling
• Quick guide
• Safety guide

Specification

  • USB C interface for charging: Input voltage typ. 5.0 V
  • Charging temperature 0 °C – 60 °C (32 °F – 140 °F)
  • Charging time typ. 3 h
  • Battery pack: Cell type Li-Ion
  • Nominal voltage 3.7 V
  • Cell capacity 850 mAh
  • Operating time up to 5 h
  • AF characteristics: Codec aptX® Live
  • Audio frequency response 3.5 mm Jack/XLR: 80 – 18,000 Hz
  • 6.3 mm Jack: 10 – 18,000 Hz
  • Audio output max. 12 dBu
  • Signal-to-noise ratio ≥ 106 dB
    THD < 0.1 %
  • Audio latency < 4 ms
  • Product properties:Dimensions
  • XSW-D XLR FEMALE TX approx. 102 x 24 x 28 mm
  • XSW-D MINI JACK TX approx. 86 x 24 x 28 mm
  • XSW-D INSTRUMENT TX approx. 122 x 24 x 28 mm
  • XSW-D XLR MALE RX approx. 109 x 24 x 28 mm
  • XSW-D MINI JACK RX approx. 86 x 24 x 28 mm
  • XSW-D INSTRUMENT RX approx. 122 x 24 x 28 mm
  • XSW-D PEDALBOARD RX approx. 130 x 82 x 51 mm
  • Frequency range 2,400 – 2,483.5MHz
  • Transmission power (EIRP) max. 10 mW
  • Modulation GFSK with TDMA
  • Environmental conditions:
    Operating temperature -10 °C to +55 °C
    (14 °F to 131 °F)
  • Relative humidity 95 % (non-condensing)
