SmallHD Vision 24 Inch HDR Monitor
£16,260.00 £13,550.00
SmallHD Vision 24 Inch HDR Monitor
SmallHD Vision 24 Inch HDR Monitor (SHD-MON-VISION-24). Vision 24 allows you to see as your camera sees.
Engineered to equal modern sensors’ increased sensitivity to highlight and lowlight image retention. Powered by SmallHDR, a proprietary Full-Array Local Dimming (FALD) hardware that enables nuanced control of over 2176 individual LED zones, rendering hyper-sharp contrasts with deep blacks, crisp highlights, and a stunning 10-bit color depth. Ideal for use in any production environment where HDR monitoring is a necessity, Vision 24 provides the added security that every detail is captured.
Key Platform Highlights
- PageOS 4 software platform
- 4K HDR waveform and scopes
- Color Pipe HDR color rendering
- Monitor Calibration Wizard
- Small4K™ Video Processing Architecture
- Inputs: 4x 12G-SDI , 1x HDMI 2.0
- Outputs: 4x 12G-SDI
- Unibody Smart Chassis
- Dovetail Mounting Rail for battery and accessory mounting
- Interchangeable mounting points
- 2x 2-pin accessory power outputs
- Power: Hot-swappable dual inputs: 1x 3-pin XLR, 1x Dual-GM/VM Battery Plate (sold separately)
Additional information
| BRAND | SMALLHD |
|---|---|
| SCREEN SIZE |
Specification
Environmental
Item Weight (oz)
315.2
Display
Panel Type
IPS LCD
Diagonal Size
24.1
Resolution
4096×2160
Brightness
1000nits
Contrast
1,000,000:1
Gamut
115% DCI-P3
Color Depth
True 10-bit
Viewing Angle
90 Degrees
Backlight Type
Full-Array Local Dimming
Backlight Zones
2176
Display Size
24″
Panel Resolution
4096 x 2160
Brightness
1000nits
Color Bit Depth
True 10-bit
Backlight Type
Full-Array Local Dimming
DCI-P3 Color
115% DCI-P3
EVF
Height (in)
15.8 (w/out feet and handle) 16.9 (w/ feet and handle)
Width (in)
23.4 (w/out feet and handle) 23.7 (w/ feet and handle)
Depth (in)
2.8 (w/out feet and handle) 4.7 (w/ feet and handle)
Weight
19.7lbs/8.9kg
Input Signal
12G-SDI Input Types
4x 12G-SDI
HDMI Input Types
1x HDMI 2.0 (4K60)
Output Signal
12G-SDI Output Types
4x 12G-SDI
HDMI Output Types
Coming Soon
Audio Output Types
1x 3.5mm 3-pin Stereo Headphone Jack
Data I/O
Connector Type
1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI
Power
Input
1x 3-pin XLR (310W max, 12V-34V, 26A max)
Output
2x 2pin (12V / 2A combined) 1x USB (2.4A) (Front) 1x USB (1.5A) (Front) 1x USB-C (5V / 1.5A)
Consumption
225w (monitor only) 306w (w/max access. power draw)
Battery Plate Included
No
Battery Types
1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)
What's Included
- Basic Acrylic Screen Protector
- 3ft 4K HDMI Cable
- 2x 1/4-20 Cheese Stick Mounting Accessory
- 2x Combo Cheese Stick (1/4-20 + 3/8″)
- Monitor Feet
- Monitor Handle
- 3-pin XLR Power Supply
- 8GB SD Card
- Microfiber Cleaning Cloth
