DJI SDR Transmission Combo

Description

DJI SDR Transmission Combo (CP.RN.00000397), offers a minimal latency of just 35 milliseconds, ensuring smooth monitoring and efficient collaboration. This technology supports metadata transmission from mainstream cinema cameras, providing quick access to detailed shooting information in real time. It also enables one-on-one real time communication between the receiver and transmitter, allowing seamless conversations between the cinematographer and the director or client at any time.

Built around Software-Defined Radio technology, DJI SDR Transmission utilizes both SDR and Wi-Fi video transmission modes. SDR technology takes video transmission performance to a whole new level, offering enhanced stability, interference resistance, and penetration capabilities. For instances that require temporary monitoring, DJI SDR Transmission also accommodates Wi-Fi transmission to provide teams with increased flexibility.

Users have access to a variety of features such as control for the RS Series Stabilizer, channel settings, camera control and boundless potential. This technology utilizes both SDR an WI-FI video transmission modes, offering enhanced stability, interference resistance and penetration capabilities. It also supports high bitrate and high-quality image transmission, as well as multiple monitoring methods and options for comprehensive connectivity and power supply solutions.

Features:

SDR Transmission, Stable & Anti-interference

DJI SDR Transmission utilizes SDR technology to offer enhanced stability, interference resistance, and penetration capabilities. It also supports transmitting directly to smartphones or tablets via Wi-Fi.

Strong Penetration, Extended Transmission Distance

DJI SDR Transmission features a transmission distance of up to 3 km/10,000 ft, suitable for wide-area mobile filming scenarios, and advanced penetration capabilities.

20Mbps High Bitrate 1080p, FHD Image Quality

DJI SDR Transmission supports 1080p/60fps video specifications with a transmission bitrate of up to 20 Mbps and a minimal latency of just 35 ms.

Innovative USB-C Monitoring Experience

DJI SDR Transmission introduces a USB-C output monitoring method. Users can now use a USB-C cable to connect the receiver to a smartphone or tablet.

Broadcast Mode, Unlimited number of Receivers

In Broadcast mode, each transmitter can connect to an unlimited number of receivers, providing a high-quality monitoring experience.

Ronin Compatibility & Remote Control

DJI SDR Transmission supports control of the RS series stabilizers, remote camera control, various monitoring assistance, and camera source switching.

DJI SDR Transmission Boundless Potential

• SDR Transmission, Stable & Anti-Interference
• Strong Penetration, Extended Transmission Distance
• High Bitrate, High Image Quality
• Innovative USB-C Monitoring Experience
• Broadcast Mode, Unlimited Number of Receivers
• Ronin Compatibility & Remote Control

Metadata Transmission for Professional Use Cases

DJI SDR Transmission supports metadata transmission from mainstream cinema cameras like ARRI and RED via SDI. This provides directors, cinematographers, and DIT teams with quick access to detailed shooting information in real time.

Control for the RS Series Stabilizers

Supports Force Mobile, virtual joystick, and gimbal recentring functions.

Channel Settings

When DJI SDR Transmission is connected to the app in SDR Control mode or Wi-Fi mode, users can switch channels within the app and monitor channel quality simultaneously.

Camera Control*

DJI SDR Transmission supports PTP control over cameras, displaying and adjusting aperture, shutter, ISO, and even triggering the camera’s photo-taking and video-recording functions through the app. Additionally, it supports CEC control for Sony cameras, bringing Mirror Control mode into play.

Compact, Lightweight, Portable

With a lightweight design and foldable antennas for easy storage, a single transmitter or receiver weighs approximately 145 g. This not only ensures portability but also supports various mounting methods, satisfying a wide range of on-scene demands.

Newly Upgraded DJI Ronin App
When DJI SDR Transmission is connected to the DJI Ronin app in Broadcast mode, users can seamlessly switch between camera indexes within the app, meeting the monitoring needs for different camera views. The app supports local recording, and recorded content can be reviewed on the playback page. The app supports mainstream monitoring assistance tools such as LUT, peaking, waveform, and false colour, delivering a professional monitoring experience.

Comes With

• 1 x DJI SDR Transmission Transmitter (TX)
• 1 x DJI SDR Transmission Receiver (RX)
• 1 x USB-A to USB-C Cable (43 cm)
• 1 x TX Camera Mounting Adapter Plate
• 1 x TX Gimbal Mounting Adapter Plate
